Micro Glass Fiber Coalescer Filter Element JPMG 336-CE-R High Efficiency

Name: Micro Glass Fiber Coalescer Filter Element JPMG 336CER High Efficiency
Brand: Filterk
Price: 1 USD

Wholesale Micro Glass Fiber Coalescer Filter Element JPMG 336-CE-R High Efficiency from china suppliers

Brand Name : Filterk

Model Number : JPMG 336-CE-R

Certification : ISO SGS

Place of Origin : China

MOQ : 10 pcs

Price : negotiation

Payment Terms : T/T, Western Union

Packaging Details : Plastic bag inside,carton outside. Optional: Pallet or wooden case for large quantities.(Need extra cost)

After-sales Service Provided : No overseas service provided

Recommended Change-Out DP : 15 psid

Operating Temperature : -46~+110 ℃

Dimension : 114(OD)*83(ID)*914(H)

Filtration Efficiency : 99.9%

Design Specifications : SME VIII div.1,GB150,EN13445

Filtering Accuracy : 0.3 Micron

OEM : Yes

Contact Now

Replacement Jonell JPMG 336-CE-R coalescing filter cartridges with high efficiency

Coalescing filter cartridges are high efficiency, inside to outside flow direction elements specificallydesigned for the removal of liquid and solid contaminant in critical applications.

Filterk’s are available in various grades of absolute rated high performance micro glass, polyester, and polypropylene media with hardware customizable to suit your application.

Dimensions:

Length	914mm
Inside Diameter	79.5mm
Outside Diameter	114mm
Flow Pattern	Inside to Out

*Above dimensions are nominal in mm.

Materials:

Coalescing Media: Micro Glassfiber

Drain Layer:Needled Polyester

Inner Core: Stainless Steel

Supports: Stainless Steel

End Caps: Stainless Steel

Gaskets:Buna

Performance:

Standard Micron Rating:0.3 µ

Recommended Initial DP < 0.5 psid

Recommended Change-Out DP :15 psid

Maximum Temperature:300° F

Single Open End

ISO 9001:2008 Certified

Micro Glass Fiber Coalescer Filter Element JPMG 336-CE-R High Efficiency
